Sunday Park Ranger Frame

Sunday Park Ranger Frame - 100% 4130 Chromoly - Park and transition inspired geometry. - Nightshift style, double-butted, top and down tubes with proven internal gusseting. - Integrated seat clamp - Butted Seat Tube & Miter Cut Top Tube: A miter-cut top tube creates a precise joint with the seat stays during welding. This increases the strength substantially over frames that use a “sandwiched” top tube at this critical junction. - Tapered Chain & Seat Stays: Both chain and seat stays taper to provide a refined and clean look to the frame while still providing strength. They are both angled on the inside for improved chain clearance and weight savings. - Hollow Dropouts with Chain Tensioners: Hollow 8mm wide dropouts are as light as a solid 5mm dropout, but over twice as strong. There is a small internal chain tensioner to hold the wheel in position and to simplify wheel removal. - Removable Brake Hardware: Proven, removable, brake mounts and cable guides/stops work flawlessly when installed and allow for a sleek overall look when they’re not. Top Tube Lengths: 20.5", 20.75", or 21" Head Tube Angle: 75.25° Seat Tube Angle: 71° Chainstay Length: 12.70-13” Bottom Bracket Height: 11.625” Standover: 7.625” Tire Clearance: 2.4” Head Tube Length: 4.8” Weight: 5lbs
